#2: EGR System, Non CA Models (TBI)
| 1. EGR Valve | 7. Brake Light Switch | 13. Pressure Sensor |
| 2. EGR Modulator | 8. Lock-up Relay (A/T) | 14. Fifth Gear Switch (M/T) |
| 3. Vacuum Switching Valve (VSV) | 9. Lock-up Solenoid (A/T) | 15. Exhaust Gas |
| 4. Main Switch | 10. ECM | 16. Vacuum |
| 5. Battery | 11. Ignition Coil | 17. Air |
| 6. Control Relay | 12. Coolant Sensor | 18. Throttle Position Sensor (TPS) |
